主要功能特点：

用于测量汽车排放废气中的HC、CO、NOx气体浓度，采用国外技术，进口关键零部件组装而成。

具有高亮度数码显示，自动校零，自动数据线性化处理，气路阻塞时自动报警，故障时自动诊断所在单元，

打印测试之日期、时间功能，配内置打印机（或蓝牙、RS232、模拟接口），可进行自由怠速和双怠

速测量，具有操作方便，测量数据准确，工作稳定可靠等特点。

主要技术参数：

测量范围        HC：0～10000×10-6（ppm）vol
CO: 0～10   ×10-2(%)vol
NOx :0～4000 ×10-6（ppm）vol
示值误差        HC±12  ×10-6（ppm）vol(绝对误差)或±5%(相对误差)
CO±0.06×10-2(%)vol    (绝对误差)或±5%(相对误差)
NOx ± 25×10-6（ppm）vol(绝对误差)或±4%(相对误差)
重 复 性         重复误差≤±2%
分 辨 率         HC：1×10-6（ppm）vol
CO: 0.01×10-2(%) vol
NOx:1×10-6（ppm）vol
稳 定 性         自动校零，量矩漂移≤±3%
预热时间        8min（可预热3min应急检测）
响应时间        95%响应不大于10秒
输出方式        数字直读显示，可附打印机打印气体名称，浓度最大值，测
试时间、日期等。可附接口与计算机联网
环境条件        温度-5～50℃，相对湿度≤90%
电      源         AC100-240V 50/60Hz 或DC12V（选加电源逆变器）
消耗功率40VA
外形尺寸        420mm(长)×310mm(宽)×170mm(高)
重      量         约9KG

Main Features:

Used to measure vehicle emissions of HC, CO, NOx gas concentration, using advanced

foreign technology, import the key components assembled. With a high-brightness

digital display, automatic zero, linear automatic data processing, auto-alarm when the

gas line blocking, fault diagnosis where the unit automatically and print testing date,

time functions, with built-in printer (or the analog output interface or Bluetooth / RS232A interface), can be freely idling and dual idling measure, with easy

operation, accurate measurement data, work stable and reliable characteristics.

Main technical parameters:

Measuring range:HC: 0~10000×10^-6(ppm)vol

CO: 0~10×10^-2(%)vol )

NOx :  0~4000×10^-6(ppm)vol

Indicating error: HC±12×10^-6 (ppm)vol( absolute error ) or±5% ( relative error )

CO±0.06×10^-2(%)vol ( absolute error ) or±5% ( relative error )

NOx±25×10^-6 (ppm)vol ( absolute error ) or±4% ( relative error )

Stability:moment drift≤±3%

Repeatability ≤±2%

Resolution: HC:1×10^-6(ppm)vol

CO: 0.01×10^-2(%)vol

NOx: 1×10^-6(ppm)vol

Response time: 95% response is not more than 10 seconds

Preheating time: 8min ( preheating 3min emergency detection )

Output mode: digital direct reading, gases can be attached printer name, the maximum concentration,

average value, minimum value, test time, date. Can interface with computer networking

And-use temperature: -5~50°C, Relative humidity: ≤90%

Power: AC100~240V 50/60Hz or DC12V( Add power inverter)

Power consumption: 40VA

Dimension: 420 (L )×310(W)×170(H)mm

Weight: 9kg
